BV011 BRASS PRESS X ROTATING FLANGE BALL VALVE WITH DRAIN
Specification
● Forged Brass Body
● PRESS Conform IAPMO PS117
● Designed specifically for use in COPPER(PEX/CPVC)piping system
● Blow Out Proof Stem Design
● Packing Nut & 0-RING
● Handle With Vinyl Grip
Performance Rating
● Max Working Pressure 200psi
● Max Working Temperature 200°F Water Service
Certification
● cUPC、NSF/ANSI 61 and NSF/ANSI 372 Approved
Model & Structure Dimension
| Model | Size | Port |
| BV011B050 | 1/2" | 0.524" |
| BV011B075 | 3/4" | 0.748" |
| BV011B100 | 1" | 0.984" |
| No. | Name | Material | QTY |
| 1 | Body | C37700 | 1 |
| 2 | Sealing washer | PTFE | 2 |
| 3 | Ball | C37700 | 1 |
| 4 | O-Ring | NBR | 1 |
| 5 | Packing Nut | C37700 | 1 |
| 6 | Stem | C37700 | 1 |
| 7 | Handle Nut | Steel | 1 |
| 8 | Lock Washer | Steel | 1 |
| 9 | Ball Packin | PTFE | 1 |
| 10 | Handle | Steel | 1 |
| 11 | Cap | C37700 | 1 |
Product Features
Brass press x rotating flange ball valve full port with Drain, cUPC、NSF/ANSI 61 and NSF/ANSI 372 Approved.
Forged brass body removes sand hole, makes body stronger.
Suitable for frequent operation, quick opening and closing.
Good sealing performance.
The flow of medium can be both direction.
Blow out proof stem design brings more pressure resistance.
Strict visual inspection, 100% water and air pressure test make sure no leakage and good performance.
Product Description
1. Use lead free brass, no harm to body.
2. Brass color body, also can nickel plate.
3. Valve can stand 200Psi pressure.
4. Valve can be used for water, oil and gas.
5. Customer logo can be put on the handle sleeve.
6. Packed in inner box. Label tag can be used individual for retail market.
Our Advantage
1. We accumulated rich experience through cooperation with many customers of different demands for more than 20 years.
2. In case any claim occurred, our product libility insurance can look after to eliminate the risk.
FAQ
1. Can I give a sample order?
A: Yes, we welcome sample order to test or check quality.
2. Is there any MOQ limit for our order?
A: Yes, most of the items have MOQ limit. We do accept small qty at the beginning of our cooperation so that you can check our products.
3. How to ship the goods and how long to deliver the goods?
A. Usually the goods shipped by sea. In general, the leading time is 25 days to 35 days.
4. How to control the quality and what's the guarantee?
A. We buy goods only from reliable manufacturers, all carry out comprehensive quality inspection during every step of production procedure. We send our QC to inspect goods strictly and issue report to customer before shipment.
We arrange shipment after goods passed our inspection.
We offer certain period warranty to our products accordingly.
5. How to deal with the unqualified product?
A. If defective occurred occasionally, shipping sample or stock will be checked first.
Or we will test the unqualified product sample to find the root cause. Issue 4D report and give final solution.
6. Can you produce according to our design or sample?
A. Sure, we have our own professional R&D team to follow your requirement. OEM and ODM are both welcomed.
